This downloadable AutoCAD block provides a clean and editable representation of the Doughty T57001, The industry standard slimline half coupler. A high tensile extruded aluminium clamp that is suitable for 48mm to 51mm
🛠️ Tech Specs
Tube Diameter: 48mm to 51mm
Working Load Limit (WLL): 750 kg
📦 Files Included:
RIG#DOUGHTY - SLIMLINE HALF COUPLER [T57001]
🔧 Download Notes
Please note these files are 3D only, no 2D Elevations are included in this Pack
Format: AutoCAD 2018 .dwg
Last Update 09/08/25
This downloadable AutoCAD block provides a clean and editable representation of the Doughty T57001, The industry standard slimline half coupler. A high tensile extruded aluminium clamp that is suitable for 48mm to 51mm
🛠️ Tech Specs
Tube Diameter: 48mm to 51mm
Working Load Limit (WLL): 750 kg
📦 Files Included:
RIG#DOUGHTY - SLIMLINE HALF COUPLER [T57001]
🔧 Download Notes
Please note these files are 3D only, no 2D Elevations are included in this Pack
Format: AutoCAD 2018 .dwg
Last Update 09/08/25
⚠️ Disclaimer:
This drawing set has been independently edited and prepared for convenience and ease of use from original vendor drawings. While care has been taken to ensure accuracy, we accept no responsibility for any errors, omissions, or issues arising from the use of these files.
Users should verify all dimensions and details against official specifications before using them in any regulated or commercial project.
